Swivel caster 1.57 in

Stylea
Order number: 990770013
detail.eanLabel 4031582359855
Product number: 5920PJI040L51-10 LH 9011/9011/7016
  • Non-hazardous materials
  • Tested quality
  • Colour matching
The Stylea swivel caster is a versatile mobility solution engineered for applications including bedside tables, furniture, media... Details
Custom or high volume? Request a quote now.
You have saved products in your offer list Request now

CAD files

Data sheets

The Stylea swivel caster is a versatile mobility solution engineered for applications including bedside tables, furniture, media furniture, and office furniture. This caster features a blind hole for B10 fitting, enabling secure and straightforward installation on compatible equipment. The housing is constructed from polyamide, a durable engineering polymer that provides excellent chemical resistance and mechanical strength, while incorporating a stem swiveling mechanism that allows for smooth directional changes and enhanced maneuverability. The wheel assembly comprises a 1.57 inch diameter wheel with a thermoplastic rubber tread material bonded to a polypropylene body, delivering reliable performance across various floor surfaces while minimizing noise and vibration. The wheel is supported by a plain bearing with spacer tube, ensuring smooth rotation and extended operational life. The overall height of the caster measures 1.38 inches, making it suitable for compact furniture applications where space constraints are critical. This caster is rated for a static load capacity of 176.37 pounds, accommodating substantial weight loads in stationary applications, while the dynamic load capacity reaches 88.18 pounds at a maximum speed of approximately 1.86 miles per hour, ensuring safe and controlled movement when the caster is in active use. These specifications make the Stylea swivel caster an ideal choice for furniture requiring reliable mobility and load-bearing performance.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Artikelnummer
5920PJI040L51-10 LH 9011/9011/7016
EAN
4031582359855
S4 Materialnummer
990770013
Core attributes
Gehäusetyp
Swivel caster
Gesamtbreite
2.05 in
Tragfähigkeit bei 3 km/h
88.18 lb
Statische Tragfähigkeit
176.37 lb
Bauhöhe
1.38 in
Temperaturbereich (Maximum)
140 °F
Temperaturbereich (Minimum)
-4 °F
Gesamtgewicht
0.11 lb
Produktname
Stylea
Norm
EN12528 - Furniture Castors
Elektrisch-leitfähig
Rostfrei
Fitting
Befestigungsart
Blind hole for B10 fitting
Rückenloch Durchmesser
0.39 in
Housing
Farbe
Graphite black (RAL9011)
Gabelform
Twin wheel housing
Material
Polyamide
Schwenklager
Stem, swiveling
Dom Durchmesser
0.6 in
Störkreis
2.91 in
Ausladung
0.47 in
Schwenkradius
1.46 in
Wheel
Härte der Lauffläche (A)
87 Shore A
Material des Radkörpers
Polypropylene
Material der Lauffläche
Thermoplastic rubber
Achsloch Durchmesser
0 in
Nabenlänge
0 in
Breite der Lauffläche
0.47 in
Durchmesser
1.57 in
Breite des Radkörpers
0.47 in
Fadenschutz
Without threadguard
Laufflächenfarbe
Anthracite gray (RAL7016)
Achse
Riveted
Lager
Plain bearing with spacer tube
Radfarbe
Graphite black (RAL9011)
special-features-image
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic hydrocarbons or chromium (VI)
Tested quality
Tested in our own laboratory for compliance with European standards
Variable fitting options
Different fitting dimensions for a wide range of applications
Colour matching
Colors can be adapted to match the product design
Painted surface
Gold, chrome, or glossy colors
Visual integration
Different dome diameters for a perfect transition from the castor to the application
Non-marking movement
Wheels with reduced abrasion and minimal cleaning requirements
Chemical-resistant components
Insensitive to many cleaning agents and chemical substances
Optimised manoeuvrability
Twin wheel castor with high maneuverability due to differential effect
Reduced cleaning
Thanks to mainly smooth surfaces, castors are quick and easy to clean
