Wheel 3 in
Supratech
detail.eanLabel
4031582436013
Product number:
PJO3x1.25-Ø0.5 HL40
- Non-hazardous materials
- Tested quality
- Non-marking movement
The Supratech wheel is a 3 inch diameter caster wheel engineered for demanding industrial and commercial applications including ...
Details
Custom or high volume? Request a quote now.
Data sheets
The Supratech wheel is a 3 inch diameter caster wheel engineered for demanding industrial and commercial applications including roll cages, shopping trolleys, store fixtures and displays, tool cabinets, work benches, and transport equipment. The wheel features a thermoplastic rubber tread with a width of 1.25 inches mounted on a polypropylene body, supported by a plain bearing system. The hub measures 1.57 inches in length with an axle hole diameter of 0.48 inches. This wheel is rated for a static load capacity of 352.74 pounds and a dynamic load capacity of 176.37 pounds at speeds up to 1.86 miles per hour, making it suitable for applications requiring reliable performance and durability in demanding environments.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic hydrocarbons or chromium (VI)
Tested quality
Tested in our own laboratory for compliance with European standards
Non-marking movement
Wheels with reduced abrasion and minimal cleaning requirements
