Swivel castor 2.95 in

Linea light

detail.eanLabel 4031582420531

Product number: 5920PJI075S70-10x15/10 scan RAL9002

Non-hazardous materials
Tested quality
Colour matching

The Linea light swivel caster features a threaded stem with hexagon neck, top fitting for secure mounting applications. The hous... Details

Features

2.95 mm
3.13 mm
66.1400 kg

Wheel

Wheel Diameter

Housing Color

Housing

Fitting

Custom or high volume? Request a quote now.

Data sheets

The Linea light swivel caster features a threaded stem with hexagon neck, top fitting for secure mounting applications. The housing is constructed from durable polyamide material and incorporates a stem, swiveling bearing system for smooth directional changes. The wheel assembly consists of a polypropylene body with thermoplastic rubber tread material, utilizing a plain bearing with spacer tube for reliable operation, and measures 2.95 inches in diameter. The caster has an overall height of 3.13 inches, making it suitable for compact installations. Load specifications include a dynamic capacity of 66.14 lb at speeds up to 1.86 mph and a static load capacity of 132.28 lb, ensuring reliable performance across various applications including anesthesia carts, bedside tables, medical imaging equipment, catering systems, mobile computers, dialysis carts, furniture, media equipment, medication carts, nursing carts, office chairs, ultrasound equipment, ventilators, and professional cleaning carts in healthcare, office, and institutional environments.

Roll performance

Movement noise

Attrition

Corrosion resistance

Article numbers

Article Number

5920PJI075S70-10x15/10 scan RAL9002

EAN

4031582420531

Core attributes

Type

Swivel castor

Overall width

2.17 in

Load capacity at 3 km/h

66.14 lb

Load capacity Static

132.28 lb

Overall height

3.13 in

Temperature range (Maximum)

140 °F

Temperature range (Minimum)

-4 °F

Overall weight

0.36 lb

Product name

Linea light

Standard

EN12528 - Furniture Castors

Electric conductive

Stainless

Fitting

Fitting type

Threaded stem with hexagon neck, top

Stem diameter

0.39 in

Stem length

0.59 in

Housing

Color

Gray white (RAL9002)

Fork shape

Twin wheel housing

Material

Polyamide

Swivel bearing

Stem, swiveling

Dome diameter

1.18 in

Swivel interference

5.12 in

Offset

0.91 in

Swivel radius

2.56 in

Thread diameter

0 in

Wheel

Hardness of tread (A)

92 Shore A

Body material

Polypropylene

Tread material

Thermoplastic rubber

Tread width

0.59 in

Diameter

2.95 in

Threadguards

Without threadguard

Bearing

Plain bearing with spacer tube

Deutscher Designer Club

Interzum Award

IF Design Award

Special Features

detail.specialFeatures.subtitle

Non-hazardous materials

Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic hydrocarbons or chromium (VI)

Tested quality

Tested in our own laboratory for compliance with European standards

Colour matching

Colors can be adapted to match the product design

Award-winning design

Awarded with prestigious prizes by international juries

Non-marking movement

Wheels with reduced abrasion and minimal cleaning requirements

Optimised manoeuvrability

Twin wheel castor with high maneuverability due to differential effect

Individual branding

Engraved, cast, or printed

Fascinating picture prints

Entire wheel caps printable with almost any theme
