Accessory

E-Drive handle set
detail.eanLabel 4031582503968
Product number: EDOZ300
  • Non-hazardous materials
  • Tested quality
  • Standardised maintenance
The E-Drive handle set is an accessory designed to enhance the functionality and usability of electromobility devices equipped w... Details
Custom or high volume? Request a quote now.
You have saved products in your offer list Request now

CAD files

Data sheets

The E-Drive handle set is an accessory designed to enhance the functionality and usability of electromobility devices equipped with casters. This handle set provides operators with improved ergonomic control and maneuverability, facilitating smooth directional guidance and precise positioning of the mobility unit. The accessory integrates seamlessly with existing electromobility platforms, offering a secure grip interface that accommodates various hand sizes and operating preferences. Engineered for durability and reliability, the handle set withstands repeated use in demanding environments while maintaining consistent performance characteristics. The design prioritizes user safety and comfort during extended operation periods, reducing operator fatigue and enhancing overall handling efficiency. Installation is straightforward, requiring minimal modifications to the base mobility unit. This accessory is compatible with standard caster configurations and supports optimal weight distribution across the mobility platform. The E-Drive handle set represents a practical enhancement for professionals and operators seeking improved control and operational precision in electromobility applications.
Article numbers
Article Number
EDOZ300
EAN
4031582503968
Core attributes
Type
Accessory
Overall weight
2 lb
Product name
E-Drive handle set
Electric conductive
Stainless
Handle Set
Controller
Safety-tested in accordance with DIN ISO 13849
Emergency stop button
Handle material
Glass-fiber reinforced polyamide
LED-functionality
Shows the status of the drive unit
Cable length (including plug)
11.48 FEET
Permissible ambient temperature for storage (Maximum)
113 °F
Permissible ambient temperature for storage (Minimum)
14 °F
Permissible ambient conditions for operation
5 to 50 °C , atmospheric humidity 90%, non-condensing
Positions of thumb depression on controller
Adjustable in 22,5° steps
Protection type
IPX4 (splash water from all sides) when horizontally mounted
Service life of controller
2 million cycles
Set components
Two ergonomically designed handles, one with and one without function
Speed control
Continuously variable, forwards and backward
Controller axle rotation angle (Maximum)
45
Controller axle rotation angle (Minimum)
-45
special-features-image
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic hydrocarbons or chromium (VI)
Tested quality
Tested in our own laboratory for compliance with European standards
Standardised maintenance
USB interface for firmware updates
User-friendly assembly
Handheld control unit can be flexibly attached in vertical or horizontal position
Reduced absences due to illness
Rapid return on investment through fewer illness-related absences
