levina

Levina
Order number: 990037406
EAN: 4031582368758
Product number: 5377PJP125P30-11 7001/3000
  • Non-hazardous materials
  • Tested quality
  • Colour matching
The Levina swivel castor with total lock is a precision-engineered mobility solution designed for demanding healthcare and comme... Details
Features
  • 125 mm
  • 161 mm
  • 100 kg
Custom or high volume? Request a quote now.
You have saved products in your offer list Request now
The Levina swivel castor with total lock is a precision-engineered mobility solution designed for demanding healthcare and commercial environments, featuring a bolt hole fitting that ensures secure and straightforward installation onto equipment frames and bases. The housing is constructed from durable polyamide material and incorporates two ball races within the swivel bearing assembly, providing smooth rotational movement and reliable directional control whilst maintaining the total lock functionality for enhanced stability when the castor is stationary. The wheel comprises a 125 mm diameter design with a thermoplastic rubber tread bonded to a polypropylene body, delivering excellent grip, durability, and resistance to wear across varied floor surfaces commonly encountered in hospitals, care facilities, and commercial settings. With an overall height of 161 mm, the castor integrates seamlessly into standard equipment configurations whilst maintaining appropriate ground clearance for operational efficiency. The load capacity specifications indicate a static load rating of 200 kg, ensuring robust support for stationary equipment, whilst the dynamic load capacity of 100 kg at 3 km/h accommodates safe mobility at controlled speeds typical of anesthesia carts, medication carts, dialysis carts, nursing carts, care beds, computers on wheels, catering carts, meal delivery systems, professional cleaning carts, shopping trolleys, store fixtures, ultrasound equipment, ventilators, work benches, tool cabinets, and imaging systems including C-Arms, CT scanners, MRI units, and X-ray equipment. This comprehensive load rating and precision bearing system make the Levina castor an ideal choice for healthcare institutions, nursing and retirement homes, and professional environments requiring dependable, controlled mobility solutions.
Roll performance
Movement noise
Attrition
Corrosion resistance
Awards
Awards
019bbc1440b871199854a324630da6ee,019bb808ca2f71ceba27dde73e12ee47
Article numbers
Article Number
5377PJP125P30-11 7001/3000
EAN
4031582368758
S4 Materialnumber
990037406
Core attributes
Housing type
Swivel castor with total lock
Overall width
59 mm
Load capacity at 3 km/h
100 kg
Load capacity Static
200 kg
Overall height
161 mm
Temperature range (Maximum)
40 °C
Temperature range (Minimum)
-10 °C
Overall weight
0.58 kg
Product name
Levina
Standard
EN12530 - Devices Castors
Electric conductive
Stainless
Fitting
Fitting type
Bolt hole
Bolt hole diameter
11 mm
Housing
Colour
Silver grey (RAL7001)
Fork shape
Slim
Material
Polyamide
Swivel bearing
Two ball races
Dome diameter
59 mm
Swivel interference
201 mm
Offset
38 mm
Swivel radius
100.5 mm
Wheel
Hardness of tread (A)
87 Shore A
Body material
Polypropylene
Tread material
Thermoplastic rubber
Tread width
32 mm
Diameter
125 mm
Body width
32 mm
Threadguards
With threadguard
Bearing
Precision ball bearing
Wheel color
Silver grey (RAL7001)

Universal Design Award

Universal Design Award

Deutscher Designer Club

Deutscher Designer Club

special-features-image
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Prevents unintended movement
Wheel lock for manual operation
Secured stand
Total lock for simultaneously locking the wheel and swivel housing.
Variable fitting options
Different fitting dimensions for a large range of applications.
Colour matching
Colours can be adapted to match the product design
Award-winning design
Awarded with prestigious prizes by international juries.
Unbreakable construction
Extremely high shock absorbing.
User-friendly colour scheme
Green kickstop pedal for directional lock and red kickstop pedal for total lock.
Low-maintenance wheels
Thread guards for unobstructed operation with minimal cleaning effort.
Non-marking movement
Wheels with reduced abrasion and little cleaning requirement.
Easy steering
Double ball bearing swivel head.
Chemical-resistant components
Insensitive to many cleaning agents and chemical substances.
