Wheel 50 mm
Duratech plus
EAN:
4031582399370
Product number:
MMP050x26-Ø15
- Non-hazardous materials
- Tested quality
The Duratech plus wheel is a precision castor component manufactured from polyamide, super heavy material and featuring a double...
Details
Custom or high volume? Request a quote now.
CAD files
You can download construction data for this product.
Data sheets
The Duratech plus wheel is a precision castor component manufactured from polyamide, super heavy material and featuring a double flanged with tracks tread design. This wheel measures 50 mm in diameter with a tread width of 26 mm and incorporates a hub length of 32 mm, whilst the axle hole diameter is specified at 15 mm. The wheel is equipped with a precision ball bearing to ensure smooth operation and longevity. The load capacity specifications indicate a static load rating of 480 kg, whilst the dynamic load capacity varies depending on operational speed, with a maximum dynamic load of 200 kg at 6 km/h or 240 kg at 4 km/h. These performance characteristics make the Duratech plus wheel suitable for demanding industrial and commercial castor applications requiring reliable load distribution and sustained operational performance.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
