Wheel 150 mm
Duratech
Order number:
199801045
EAN:
4031582322699
Product number:
TOP 150x50-Ø20 HL60
- Non-hazardous materials
- Tested quality
- Low wear and tear wheels
The Duratech wheel is a precision castor component manufactured from heavy-duty polyamide with a tread width of 50 mm that is id...
Details
Custom or high volume? Request a quote now.
Data sheets
The Duratech wheel is a precision castor component manufactured from heavy-duty polyamide with a tread width of 50 mm that is identical with the wheel body. The wheel features a diameter of 150 mm and a hub length of 60 mm, with an axle hole diameter of 20 mm designed to accommodate standard castor fittings. The wheel is equipped with a precision ball bearing to ensure smooth rotation and extended operational life. The static load capacity is rated at 1600 kg, whilst the dynamic load capacity varies depending on operational speed, delivering 800 kg at 6 km/h or 960 kg at 4 km/h, making this wheel suitable for demanding industrial and commercial castor applications requiring reliable performance under substantial loads.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Low wear and tear wheels
Durable wheels with extremely low wear and tear properties.
