Wheel 150 mm
Novatech
Order number:
199802328
EAN:
4031582329476
Product number:
FTP 150x50-Ø25 HL60
- Non-hazardous materials
- Tested quality
- Non-marking movement
The Novatech wheel is a precision castor component engineered for demanding industrial applications, featuring a cast iron body ...
Details
Custom or high volume? Request a quote now.
CAD files
You can download construction data for this product.
Data sheets
The Novatech wheel is a precision castor component engineered for demanding industrial applications, featuring a cast iron body with a 150 mm diameter and a 50 mm wide PUR casted premium tread for optimal grip and durability. The wheel hub measures 60 mm in length and accommodates a 25 mm axle hole diameter, ensuring compatibility with standard castor assemblies. Equipped with a precision ball bearing for smooth rotation and minimal friction, this wheel delivers exceptional performance across varied operating conditions. The load capacity specifications indicate a static load rating of 1400 kg, whilst the dynamic load capacity reaches 700 kg at 6 km/h or 840 kg at 4 km/h, providing flexibility for different speed and load requirements. These specifications make the Novatech wheel suitable for heavy-duty material handling, industrial transport, and warehouse applications where reliability and load-bearing capability are paramount.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Low-maintenance wheels
Thread guards for unobstructed operation with minimal cleaning effort.
Non-marking movement
Wheels with reduced abrasion and little cleaning requirement.
Ergonomically friendly use
Wheels with optimised roll resistance to lighten the load for the user.
