Wheel 100 mm
Duratech
Order number:
199801132
EAN:
4031582322675
Product number:
TOP 100x50-Ø20 HL60
- Non-hazardous materials
- Tested quality
- Low wear and tear wheels
The Duratech wheel is a precision castor component manufactured from heavy-duty polyamide with a tread width of 50 mm that is id...
Details
Custom or high volume? Request a quote now.
CAD files
You can download construction data for this product.
Data sheets
The Duratech wheel is a precision castor component manufactured from heavy-duty polyamide with a tread width of 50 mm that is identical with the wheel body. The wheel features a diameter of 100 mm with a hub length of 60 mm and an axle hole diameter of 20 mm, accommodating standard castor mounting requirements. The wheel is equipped with a precision ball bearing to ensure smooth rotation and longevity. The load capacity specifications indicate a static load rating of 1200 kg, whilst the dynamic load capacity reaches 600 kg at 6 km/h or 720 kg at 4 km/h, making this wheel suitable for demanding industrial and commercial applications requiring reliable performance under sustained operational conditions.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Low wear and tear wheels
Durable wheels with extremely low wear and tear properties.
