Wheel 100 mm
Duratech silent
EAN:
4031582400687
Product number:
HUR100x36-Ø12 white
- Non-hazardous materials
- Tested quality
The Duratech silent wheel is a precision castor component engineered with a hybrid damping material body and fitted with a rolle...
Details
Custom or high volume? Request a quote now.
CAD files
You can download construction data for this product.
Data sheets
The Duratech silent wheel is a precision castor component engineered with a hybrid damping material body and fitted with a roller bearing for smooth, quiet operation. The wheel features a diameter of 100 mm with a polyamide tread measuring 36 mm in width, providing excellent wear resistance and durability. The hub length extends 44 mm, whilst the axle incorporates a 12 mm hole diameter for secure mounting. This wheel is rated for a static load capacity of 320 kg and a dynamic load capacity of 160 kg at speeds up to 4 km/h, making it suitable for demanding industrial and commercial applications requiring reliable performance under substantial loads.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
