Wheel 160 mm
Novatech
Order number:
199839136
EAN:
4031582332179
Product number:
ITP 160x50-Ø25 HL60 soft cv
- Non-hazardous materials
- Tested quality
- Non-marking movement
The Novatech castor wheel features a robust aluminium body construction with a 160mm diameter and 50mm wide casted polyurethane ...
Details
Custom or high volume? Request a quote now.
CAD files
You can download construction data for this product.
The Novatech castor wheel features a robust aluminium body construction with a 160mm diameter and 50mm wide casted polyurethane tread, incorporating precision ball bearing technology for smooth operation. The wheel dimensions include a 25mm axle hole diameter and 60mm hub length, providing secure mounting capabilities. Load specifications demonstrate exceptional performance with a static load capacity of 1100kg, whilst dynamic load capacities reach 550kg at 4km/h operating speed and 440kg at 6km/h, making it suitable for demanding industrial applications requiring reliable mobility solutions.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Non-marking movement
Wheels with reduced abrasion and little cleaning requirement.
Ergonomically friendly use
Wheels with optimised roll resistance to lighten the load for the user.
