Wheel 125 mm
Supratech
EAN:
4031582482669
Product number:
YGO125x30-Ø12 TFR
- Non-hazardous materials
- Tested quality
- Non-marking movement
The Supratech wheel is a precision castor component engineered for demanding industrial and commercial applications including ro...
Details
Custom or high volume? Request a quote now.
The Supratech wheel is a precision castor component engineered for demanding industrial and commercial applications including roll cages, shopping trolleys, store fixtures and display systems, tool cabinets, work benches, and transport equipment. This wheel features a diameter of 125 mm with a tread width of 30 mm, constructed from thermoplastic rubber with electric-conductive properties to ensure safe operation in sensitive environments. The hub measures 34.9 mm in length and accommodates a 12 mm axle hole diameter, whilst the polypropylene body with electric-conductive characteristics provides durability and static dissipation. The wheel is equipped with a plain bearing for smooth rotation and reliable performance. Load capacity specifications indicate a static load rating of 200 kg and a dynamic load rating of 100 kg at speeds up to 3 km/h, making this wheel suitable for both stationary and mobile castor applications requiring robust performance and electrical safety compliance.
Roll performance
Movement noise
Attrition
Corrosion resistance
Article numbers
Core attributes
Wheel
Special Features
Non-hazardous materials
Complies with RoHS and REACH regulations. Does not contain polycyclic aromatic carbons or chromium (VI).
Tested quality
Tested in our own laboratory for compliance with European standards.
Non-marking movement
Wheels with reduced abrasion and little cleaning requirement.
Certified conductivity
Conductive version to protect users and electrical devices from electrostatic discharge.
