ICS
5328UAX125P51 INOX 7001
EAN:
4031582310313
Product number:
00030788
Haven’t found the right product yet, have special requirements or are you interested in individual solutions? Contact us.
Downloads
Datasheet
CAD Service
There are currently no files available for this product
Core attributes
| Product name | ICS |
|---|---|
| Product type | Fixed castor |
| Load capacity at 3 km/h | 100 KG |
| Load capacity Static | 200 KG |
| Temperature range (Minimum) | -10 °C |
| Temperature range (Maximum) | 40 °C |
| Overall height | 166 mm |
| Overall width | 52 mm |
| Overall weight | 0.76 KG |
Performance
| Roll performance | |
|---|---|
| Movement noise | |
| Attrition | |
| Corrosion resistance |
Housing
| Material | Polyamide |
|---|---|
| Fork shape | Slim |
| Swivel bearing | Stem, swiveling |
| Color | Silver grey (RAL7001), Silver grey (RAL7001) |
| Dome diameter | 52 mm |
Wheel
| Body material | Polyamide |
|---|---|
| Tread material | Polyurethane, injected |
| Bearing | Precision ball bearing, sealed |
| Wheel color | Silver grey (RAL7001) |
| Wheel diameter | 125 mm |
| Tread width | 32 mm |
| Wheel width | 32 mm |
| Hardness of tread (A) | 92 Shore A |
| Hardness of tread (D) | 42 Shore D |
Fitting
| Fitting type | Rectangular plate |
|---|---|
| Plate length | 95 mm |
| Plate width | 70 mm |
| Plate hole length (Maximum) | 50 mm |
| Plate hole width (Maximum) | 75 mm |
| Plate hole diameter | 11 mm |
